Another Homelink Install

bobs78

Well-known member
Joined
Jun 6, 2004
Messages
90
Location
Hot AZ
Corvette
50th AE vert - 25th SA - 54 Polo White
Here's another alternative for those who want to install a Homelink in there C5's w/o any major modification to there cars.

View attachment 9297

:upthumbs


Rain

Well-known member
Joined
Mar 3, 2003
Messages
1,816
Location
MS Gulf Coast
Corvette
2000 Coupe 6 speed
good job!


68Roadster

Well-known member
Joined
Dec 16, 2002
Messages
1,040
Location
Dallas, TX
Corvette
'68 White Vert '05 Silverado SS
We need details man......details!

Looks very good....I love this on my truck, does it work well mounted down there ( I ask this not knowing anything about the technology other than the uncluttered look it gives my sunvisor).


68Roadster

Well-known member
Joined
Dec 16, 2002
Messages
1,040
Location
Dallas, TX
Corvette
'68 White Vert '05 Silverado SS
bossvette said:
What is a "homelink"? :confused

I have 3 buttons (factory) below my rearview in the overhead console that control my garage door openers. It learns the code and you can ditch the "clip on" door openers.
Don't know that much but I think you can train it to turn on lights, etc.....


bossvette

Gone but not forgotten
Joined
May 19, 2003
Messages
3,233
Location
West Unity Ohio
Corvette
1968 1997
I'll have to look into that, it beats carrying the opener from car to car :D


bobs78

Well-known member
Joined
Jun 6, 2004
Messages
90
Location
Hot AZ
Corvette
50th AE vert - 25th SA - 54 Polo White
I got a Homelink unit on eBay for less than $30. Don't laugh it was for a KIA View attachment 9298 Here's another 4sale http://cgi.ebay.com/ebaymotors/ws/e...3842&ssPageName=MERC_VIC_ReBay_Pr4_PcY_BIN_IT

I drilled a 9/32 hole under the aux power outlet to run the two wires to it. The trim piece above the aux power plug on the console where the active handling switch is snaps off from the rear then lifts up.

The leads on the aux power outlet are pressed into the plug that attaches on the back. I pulled the plug off the back of the aux power outlet then pushed the wires out the back of the plug attached the Homelink wires and reinserted them back into the aux power plug.

To fit the Homelink in the console I removed two screws from the back of the to remove the cover. Cut down the tabs on the Homelink unit and trimmed the cover down to fit.

It works great...no problem with it being located in the console. :D


bossvette

Gone but not forgotten
Joined
May 19, 2003
Messages
3,233
Location
West Unity Ohio
Corvette
1968 1997
bobs78 said:
I got a Homelink unit on eBay for less than $30. Don't laugh it was for a KIA View attachment 9298 Here's another 4sale http://cgi.ebay.com/ebaymotors/ws/eBayISAPI.dll?ViewItem&item=8028503842&ssPageName=MERC_VIC_ReBay_Pr4_PcY_BIN_IT

I drilled a 9/32 hole under the aux power outlet to run the two wires to it. The trim piece above the aux power plug on the console where the active handling switch is snaps off from the rear then lifts up.

The leads on the aux power outlet are pressed into the plug that attaches on the back. I pulled the plug off the back of the aux power outlet then pushed the wires out the back of the plug attached the Homelink wires and reinserted them back into the aux power plug.

To fit the Homelink in the console I removed two screws from the back of the to remove the cover. Cut down the tabs on the Homelink unit and trimmed the cover down to fit.

It works great...no problem with it being located in the console. :D

Thanks I may be asking some questions once I do my install on "training" it but its bought and paid for much less then buying another remote, who knows I may do it to all my cars at that price.;LOL


PreacherNutshot

Well-known member
Joined
Aug 22, 2005
Messages
178
Location
Columbia, MO
Corvette
2004 Spiral Grey Coupe
bobs78 said:
Here's another alternative for those who want to install a Homelink in there C5's w/o any major modification to there cars.

View attachment 9297

:upthumbs

Don't you find it a PITA to open your console every time you want to raise your garage door? I mounted my conventionally to the visor.

I'm not criticizing, I'm just curious. I'm a big guy and it's a pain to try and get into my console while driving.

T

The Drakester

Guest
I bought an battery powered opener, about the size of a quarter and velcro mounted it just above the rearview mirror. Works great and out of site.


bobs78

Well-known member
Joined
Jun 6, 2004
Messages
90
Location
Hot AZ
Corvette
50th AE vert - 25th SA - 54 Polo White
PreacherNutshot said:
Don't you find it a PITA to open your console every time you want to raise your garage door? I mounted my conventionally to the visor.

I'm not criticizing, I'm just curious. I'm a big guy and it's a pain to try and get into my console while driving.

First of all its all your fault..:mad I saw your post on installing the homelink and it got me started with these things.

Yea, its more of a PITA than on the visor or in the glove box on my '78 but I wanted the conveinance without any obivious outward apperance changes to the cars. Also the install on the 03, other than triming and painting the unit cover, took less than 20 minutes.

Thanks for the idea :beer


PreacherNutshot

Well-known member
Joined
Aug 22, 2005
Messages
178
Location
Columbia, MO
Corvette
2004 Spiral Grey Coupe
bobs78 said:
First of all its all your fault..:mad I saw your post on installing the homelink and it got me started with these things.

Yea, its more of a PITA than on the visor or in the glove box on my '78 but I wanted the conveinance without any obivious outward apperance changes to the cars. Also the install on the 03, other than triming and painting the unit cover, took less than 20 minutes.

Thanks for the idea :beer

Fair enough. :L

Should I share my pics if I install my seat warmers this winter? ;)

BTW: the fit and finish looks great!


bobs78

Well-known member
Joined
Jun 6, 2004
Messages
90
Location
Hot AZ
Corvette
50th AE vert - 25th SA - 54 Polo White
PreacherNutshot said:
Fair enough. :L

Should I share my pics if I install my seat warmers this winter? ;)

BTW: the fit an finish looks great!

Thanks for the compliment :)

Seat Watmers ;LOL Hmmmm, we did have a freeze warning last night (first for the season) but only when down to 34...but nice and sunny and 63 today :cool

Maybe Seat Coolers for the summer when its 108 :mad

:w


PreacherNutshot

Well-known member
Joined
Aug 22, 2005
Messages
178
Location
Columbia, MO
Corvette
2004 Spiral Grey Coupe
bobs78 said:
Thanks for the compliment :)

Seat Watmers ;LOL Hmmmm, we did have a freeze warning last night (first for the season) but only when down to 34...but nice and sunny and 63 today :cool

Maybe Seat Coolers for the summer when its 108 :mad

:w


Go ahead, rub it in. It's 29 degrees and the wind's blowing at a steady 30mph. Damn - it just plain cold. brrrrrr.. :cry

[Where'd I put that heater kit?]
