Re: Vacuum Headlights.

B

buddyV

Guest
Re: Vacuum Headlights.

Did the 81 vette use a vacuum filter, and vacuum check valve, in their headlight vacuum system from the factory like other years? I know the parts book said it does but, I have seen some pics with and with out. thank you, Hans


bill81vette

Moderator
Joined
Jan 17, 2004
Messages
4,321
Location
Troy,NY
Corvette
1981 dark blue metallic
I don't know about the filter, but mine does have a check valve in the power booster!...


Peer81

Well-known member
Joined
May 21, 2003
Messages
2,497
Location
Netherlands
Corvette
'81 Black
I think only owners with an 81 can answer this question (looking at the same topic on the forum.com ;)) As far as I know all the vacuum lines on my 81 were original and there wasn't a filter or check valve in the lines for the headlights. There is a valve in the line for the brake booster. :)

Groeten Peter

B

buddyV

Guest
Bill81vette, and Peer81
Power booster, are you referring to the brakes? My system looks factory and I don't have the check valve, or filter for the headlights. I looked in the assembley manual and they show a drawing but, no numbers. I've seen some 81's with, and some without, maybe owers have removed. Just trying to find out which is factoy correct. Maybe one is St.Louis and the other B.G. My vette is St.Louis born.

Joined
Apr 29, 2001
Messages
2,141
Location
Rio Rancho, NM
Corvette
1981 HD Suspension; ZN1 Option
I have heard about the component in between the power booster and the manifold vacuum port referred to as a power booster filter.

Perhaps it also incorporates a check valve??;shrug

As far as the headlights, I am not sure if they do include a check valve or filter.


bill81vette

Moderator
Joined
Jan 17, 2004
Messages
4,321
Location
Troy,NY
Corvette
1981 dark blue metallic
I do believe that is what buddyv is referring to...they are the only ones in the vacuum system that I'm aware of


Peer81

Well-known member
Joined
May 21, 2003
Messages
2,497
Location
Netherlands
Corvette
'81 Black
The valve and filter Buddy is reffering to are on or just behind the intake manifold. On the back of the intake there is a 2 or 3 way vacuumport (one for the TH350) and some others. One is for the headlights, heatercontrolles and cruise control. Mine didn't have the valve or filter but I've put them on now. There are some othere errors in the Shop Manual so don't beleave everything that is in it :)

The brake booster (power booster) is the one for the brakes. I think it was a filter to prevent fuel vapor to enter the brake system (booster). I thought it also was a valve but I think the valve is inside the booster. :)

Groeten Peter

B

buddyV

Guest
Perr81, Did you notice any difference by adding the valve and filter? You talk about errors in the shop manual. Check the circuit break location for the power seats in the GM 1981 shop manual; way wrong.

Thank you for your help.
Hans

The valve and filter Buddy is reffering to are on or just behind the intake manifold. On the back of the intake there is a 2 or 3 way vacuumport (one for the TH350) and some others. One is for the headlights, heatercontrolles and cruise control. Mine didn't have the valve or filter but I've put them on now. There are some othere errors in the Shop Manual so don't beleave everything that is in it :)

The brake booster (power booster) is the one for the brakes. I think it was a filter to prevent fuel vapor to enter the brake system (booster). I thought it also was a valve but I think the valve is inside the booster. :)

Groeten Peter


TJay

Well-known member
Joined
Mar 20, 2006
Messages
157
Location
SouthWestern Ontario
Corvette
1972 Yellow Coupe
The brake booster (power booster) is the one for the brakes. I think it was a filter to prevent fuel vapor to enter the brake system (booster). I thought it also was a valve but I think the valve is inside the booster. :)

Groeten Peter

You are correct, here's a shot of that filter..
Sorry for the big picture, but I wanted to make sure you can see it..



SIXFOOTER

Well-known member
Joined
Jul 15, 2007
Messages
117
Location
Boca Raton Fl
Corvette
1981 L81 Tan Coupe
The 81 definately did have a filter in between the carb and the checkvalve. This was for the headlight system. I just ordered new ones for my car from Ecklers

Did the 81 vette use a vacuum filter, and vacuum check valve, in their headlight vacuum system from the factory like other years? I know the parts book said it does but, I have seen some pics with and with out. thank you, Hans


big2bird

Well-known member
Joined
Aug 26, 2007
Messages
178
Location
Anaheim,Ca.
Corvette
1981 Black Coupe
The 81 definately did have a filter in between the carb and the checkvalve. This was for the headlight system. I just ordered new ones for my car from Ecklers


:)Yep. Filter and a 3 port check valve. Without the check valve, the headlights will pop up when accelerating.

Joined
Apr 29, 2001
Messages
2,141
Location
Rio Rancho, NM
Corvette
1981 HD Suspension; ZN1 Option
Would these pictures help?

...

Oh yeah! I remember that mot$#$. I hate removing the shield, for this check valve and the wire looms are a PITA to keep in their proper place.
